| Gross vehicle mass | 7500 (kg) |
|---|---|
| Overall Dimension | 6770 x 2050 x 2300 (mm) |
| Max. power | 124 (91) / 2600 (Ps(kW) / rpm) |
| Emission | EURO 4 |
| Manufacturers Name | Isuzu Vietnam Co., Ltd |
| Manufacturers Address | 695 Quang Trung Street, Ward 8, Go Vap District, Ho Chi Minh City |
| Origin | Vietnam |
| Certification number of Approval (TA) | 0027/VAQ09 – 01/18 – 00 |
| Suggested retail price | 692,181,000 VNĐ |
* Applied for cabin chassis. (Price is included VAT)
| Gross vehicle mass | kg | 7500 |
| Kerb mass | kg | 2390 |
| Number of seats | person | 3 |
| Fuel tank | Liter | 90 |
| Overall Dimension (OAL x OW x OH) | mm | 6770 x 2050 x 2300 |
| Wheelbase (WB) | mm | 3845 |
| Front – Rear treat | mm | 1680 / 1525 |
| Ground clearance | mm | 210 |
| Front – rear over hang | mm | 1110 / 1815 |
| Model | 4JJ1E4NC | |
| Type | Common rail, turbo-intercooler | |
| Emission | EURO 4 | |
| Displacement | cc | 2999 |
| Bore and Stroke | mm | 95.4 x 104.9 |
| Max. power | Ps(kW) / rpm | 124 (91) / 2600 |
| Max. Torque | N.m(kgf.m) / rpm | 354 (36) / 1500 |
| Transmission | MYY6S 6 Forward & 1 Reverse |
| Max speed | km/h | 93 |
| Gradeability | % | 35 |
| Min turning radius | m | 7,06 |
| Steering system | Recirculating ball with hydraulic assisted |
| Suspension system front – rear | Dependent, leafspring, shock absorber |
| Brake system front – rear | Drum, hydraulic with vacuum servo assistance, dual circuilt |
| Tire size front – rear | 7.50-16 14PR |
| Generator | 24V-50A |
| Battery | 12V-70AH x 2 |
