| Gross vehicle mass | 3,490 (KG) |
|---|---|
| Dimension | 5,080 x 1,860 x 2,200 (mm) |
| Max .power | 105 (77) / 3,200 (Ps(kW) / rpm) |
| Emission | Euro 4 |
| Manufacturers Name | Isuzu Vietnam Co., Ltd |
| Manufacturers Address | 695 Quang Trung Street, Ward 8, Go Vap District, Ho Chi Minh City |
| Origin | Vietnam |
| Certification number of Approval (TA) | 0010/VAQ18 – 01/19 – 00 |
| List Price | 471,272,727 VNĐ |
* Applied for cabin chassis. (Price is included VAT)
| Gross vehicle mass | kg | 3,490 |
| Kerb mass | kg | 1,920 |
| Number of seats | person | 3 |
| Fuel tank | Liter | 100 |
| Overall Dimension (OAL x OW X OH) | mm | 5,165 x 1,860 x 2,240 |
| Wheel base (WB) | mm | 2,765 |
| Front – Rear treat (AW/CW) | mm | 1,398 / 1,425 |
| Ground clearance (HH) | mm | 210 |
| Front – rear over hang (FOH/ROH) | mm | 1,095 / 1,305 |
| Model | 4JH1E4NC | |
| Type | 4 stroke, in-line 4 cylinders | |
| System | Common rail, turbo-intercooler, EGR & DOC | |
| Emission | Euro 4 | |
| Displacement | cc | 2,999 |
| Bore and stroke | mm | 95.4 x 104.9 |
| Max. power | Ps(kW) / rpm | 105 (77) / 3,200 |
| Max. torque | N.m(kgf.m) / rpm | 230 / 2,000 ~ 3,200 |
| Transmission | MSB5S 5 Forward & 1 Reverse |
| Max. Speed | km/h | 96 |
| Gradiability | % | 39 |
| Min. turning radius | m | 5.7 |
| Steering system | Recirculating ball with hydraulic assisted |
| Suspension system front – rear | Dependent, leafspring, shock absorber |
| Brake system front – rear | Drum, hydraulic with vacuum servo assistance, dual circuilt |
| Tire size front – rear | 7.00 – 15 12PR |
| Generator | 12V-60A |
| Battery | 12V-70AH x 2 |
